Quick Details

  • Condition: New
  • Product Type: Toilet Tissue
  • Processing Type: Winding Machine
  • Place of Origin: Fujian, China (Mainland)
  • Brand Name: XINYUN
  • Model Number: XY-TQ-1575B
  • Voltage: 380V 50HZ
  • Power(W): 4-10 KW
  • Dimension(L*W*H): 6200X2750X1800mm
  • Weight: 4.2T
  • Certification: CE
  • Warranty: 2 years
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Machine for: 1575 Small Toilet Paper Manufacturing Machine
  • High speed: 150-200 meter/minute
  • Width of Jumbo Roll: 1.2m---2.8m
  • Embossing Roll: Steel to Rubber
  • Embossing pattern: Full or edge embossing
  • Automatic Function: Embossing--Perforating--Tail gluing--Edge Trimming--Rewinding
  • Option: Color printing or as per request
  • Color of machine: Red or blue
  • Best selling: Low price and easy operation
  • Machine design: Customize service

Packaging & Delivery

Packaging Details 1575 Small Toilet Paper Manufacturing Machine will be separated into two parts and packed in Standard Export Packing Wooden Case
1x40 foot container
Delivery Time 50 days after get the deposit
Product Description

1575 Small Toilet Paper Manufacturing Machine Price  XY-TQ-B

This equipment is to perforate and rewind the parent roll raw paper into various sizes of small toilet paper roll according to the requested. The finished product is neat, in good order and with equality tension.It's the best choice for new tissue paper factory.
1.Adopting with advanced PLC programming technology, and variable speed adjustment, electronic brake and human-machine interface operation table.
2.Horizontal type unwinding stands: pneumatic wide belt to feed paper, each jumbo roll hasindependent tension adjustor and left-right adjusting device.
3.Pneumatic lifting the jumbo roll function greatly lightens the labor intensity of the workers.
4.Auto stop machine function when material is used up will minimize the waste of raw material.
5.Continue adding roll core alarming device.
6.Rewinding Technology: The finished products from earlier loosening to later tightening when rewinding, which has solved the problem of the separation phenomenon between roll paper and roll core of the finished product after long time’s storage.
7.Auto edge trimming, glue spraying and sealing synchronously in one time.
8.The multi functions mounting on this machine has won the favor and credit among users by their excellent performance.
The production process is:


Unreel— Emboss — Perforate— Rewind — Tail-glue— Edge trim--- Automatic core load.

Video Link:

https://www.youtube.com/watch?v=KiRtuJYAJL8
https://www.youtube.com/watch?v=pzZRm__K9ZY
http://youtu.be/XCeYwrwvykU
https://youtu.be/BVXcVSvaalw

Product Name
1575 Small Toilet Paper Manufacturing Machine Price
Model
1092/1575/2000/2200/2400/2600/2800(XY-TQ-B)
Width of raw paper roll
1150/1750/1950/2150/2350/2550/2750mm
Speed
0-200m per min
Embossing units
Single or double embossing units ,steel to rubber ,full emboss or edge emboss.
Perforating Units
4 knives :the distance is 90-140mm;2 knives: the distance is 200-350mm
Pneumatical System
Air Compressor, minimum pressure 5kg/cm2pa(offered by customers)
Used Power
4kw-10kw (380V 50Hz)
Products Show
Our Company

Factory

Our Factory

Workshop

Our Workshop

Warehouse

Our Warehouse

Team

Our Team

Packing & Delivery

Packing Details : Packing, standard export wooden case
Delivery Details : 30-90 days after order

1. Special logistics packaging
2. Suitable carton size
3. Forklift Loading
Our Certifications

Best Machines

1.Xinyun's machines all have passed international certifications, like Soncap, CE and others.
2.The products we supply are at reasonable prices and in good condition and quality, and we provide supreme good after-services,including installation and training and so on.
3.We have sold many machines to over 50 countries,like the Middle East, Southern Asia, Africa, South America and East Europe. We also have won great comment from our old clients.

Customer Photo

Favorable Comment

Very expect your joins
Very expect your enquiries!!!

We will do best to reply you in the first time, to provide you more detailed information, prices, videos, and apply for a discount to support your project !!!

FAQ

Q: Are you trading company or manufacturer ?

A: We are factory.

Q: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 45-90 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
